Ground Leveling Robot

High-Precision Ground Leveling Robot with Dual-Modes Control and Laser Guidance

| Category: Concrete Works

Phone: +86 18857573798

E-mail: info@aytotech.com

Description

▶ High Quality: precise elevation control, ≥95% consistent pass rate for surface levelness, achieves ±5mm flatness during initial concrete setting with human-machine collaboration

▶ High Efficiency: 1m head-net productivity ≥100m²/h; 1.5m head-net productivity ≥160m²/h; 2.5m head-net productivity ≥300m²/h

▶ Cost Reduction: saves 2-3 manual laborers in auto/remote-control modes, 28% lower total project costs vs. traditional methods through robotic precision

▶ Intelligent Operation: unmanned autonomous construction | auto-navigation & self-planned paths | multi-robot scheduling | remote task deployment & OTA updates



Working Widths: 1m | 1.5m | 2.5m
Applications: Residential floors, underground garages, industrial plants, airports, malls – any concrete leveling scenario.

Operational Modes:
▸ Fully Automatic (requires auxiliary base station)
▸ Remote Control
Performs slurry extraction, surface finishing, and elevation control before initial concrete setting.
Modular Design: 1m/1.5m leveling heads interchangeable for multi-scene adaptability.

Specification

 Model

DZZ-1000

DZY-1500

DZY-2500

 Leveling head size

1m/1.5m double head

1.5m

2.5m

 Battery life

6h

5h

6h

 Charging time

2.5h (fast charge)

2.5h (fast charge)

3h (fast charge)

 Net productivity

1m head≥100㎡/h

1.5m head≥160㎡/h

2.5m head≥300㎡/h

 Operation Mode

remote control / automatic

remote control

remote control

 Max.moving speed

0.5m/s

0.5m/s

0.5m/s

 Max.climbing angle

10°

10°

10°

 Max.obstacle clearance height

10cm

10cm

25cm

 Machine size

165*100*165cm

165*160*165cm

265*250*200cm

 Machine weight

150kg

175kg

320kg
