Floor Smoothing Robot
Floor Smoothing Robot with 40% Higher Work Efficiency Than Traditional
Phone: +86 18857573798
E-mail: info@aytotech.com
Description
▶ High Efficiency: flatness tolerance 3mm/2m; levelness differential ≤7mm; 85% effective coverage
▶ High Accuracy: 100m²/h robotic efficiency, 40%+ crew productivity improvement vs. traditional methods
▶ Labor Savings: eliminates 3-4 screeding/surveying workers, removes secondary mortar leveling before tile/flooring installation
▶ Intelligent Operation: unmanned autonomous construction, multi-robot coordination, auto-navigation & path planning
Applications
Residential floors | Warehouses | Garages | Industrial plants | Airports | Shopping malls
(High-precision concrete smoothing scenarios)
Operational Modes
• Fully automatic (requires auxiliary base station)
• Remote-control
Performs slurry extraction, surface finishing, and elevation control for precision concrete smoothing.
Technical Highlights
• Proprietary GNSS Navigation System
• Integrated Motion Control Algorithms
• Laser Metrology & Real-time Control (±0.5mm accuracy)
• Millisecond-level Response Technology
Specification
| Name | Floor Smoothing Robot |
| Coverage | 85% |
| Climbing angle | ≤15° |
| Moving speed | ≤0.5m/s |
| Obstacle climbing height | 20mm |
| Working efficiency | ≥100㎡/h |
| IP rating | IP54 |
| Enduarce time | ≥6h |
| Charging time | 3h |
| Machine size | 1200*1000*1500mm |
| Machine weight | 140kg |
