Pavement Troweling Robot
Solve Uneven Concrete with a Underground Garage Troweling Robot for Superior Floor Quality
Phone: +86 18857573798
E-mail: info@aytotech.com
Description
▶ High Quality: superior surface compaction & abrasion resistance, enhanced finish consistency and surface levelness
▶ High Efficiency: 350m²/h per pass (2x faster than manual labor)
▶ Labor Savings: remote-control or fully autonomous mode, eliminates 1 traditional finishing worker
▶ Safety & Autonomy: auto-navigation & path planning, real-time deviation correction, anti-interference systems, unmanned operation, remote task deployment
Applications
Garages | Plazas | Industrial plants | Airports | Shopping malls
(Large-scale concrete finishing scenarios)
Operational Modes
• Fully automatic (requires auxiliary base station)
• Remote-control
Performs compaction, slurry extraction, surface finishing, and troweling on cast-in-place concrete.
Technical Highlights
• Proprietary GNSS Navigation System
• Integrated Motion Control Algorithms
• Millisecond-level Real-time Control
Specification
| Name | Underground Garage Finishing Robot |
| Working efficiency | 350㎡/h |
| Troweling diameter | 600mm |
| Turning radius | 1000mm |
| Trowel/disk speed | 0-150r/min |
| Moving speed | 0-600mm/s |
| IP rating | IP54 |
| Endurance time | ≥4h |
| Charing time | 2h |
| Machine size | 1350*750*750mm |
| Machine weight | 180kg |
